SPECIFICATION
Thickness (mm)
Width (mm)
Length (mm)
Coil ID (mm)
Hot Rolled Steel Coil
0.8~6.50
6.51~10.00
720~1860
850~1500
762
Hot Rolled Steel Strip
1.20~6.50
30~720
Hot Rolled Steel Plate
6.00~150
500~4000
1200~18000
Hot Rolled Steel Sheet
1.20~5.99
50~1845
760~6100
Hot Rolled Steel Chequered
1.20~36
1250~3250
2000~13000
STANDARD & GRADE
JIS
ASTM
SAE
Commercial Quality
G3131 SPHC
A569 A635 A659
A1011 CS Type A, B, C
1006~1025
Drawing Quality
G3131 SPHD
1006~1010
Deep Drawing Quality
G3131 SPHE
A622 A1011 DS Type A, B
General Structure (T.S. < 490N/mm2)
A36 A283 Gr.C
A570 Gr.30~40 A1001 S Gr.30~40
1010~1025
A570 Gr.45~50 A607 Gr.45~70 A1011 SS Gr.45~50 A1011 HSLAS Gr.45~70
J1392 050X
